Pulvi-Mulcher - Brillion

Pulvi-Mulcher - Brillion  Image
Pulvi-Mulcher - Brillion  Image
Pulvi-Mulcher - Brillion

The 3600 Series Pulvi-Mulcher, the latest addition to the model line-up, features wider working widths, increased trash clearance and reduced downtime in the field. The series is available in 21', 25', 30' sand 36' working widths. The 30' model weighs 80% more than the popular WL360 models for more clod crushing power. The 36' unit is the widest Pulvi-Mulcher ever offered by Brillion.


All 3600 Series model features 8" roller axles with heavy-duty bearings that improve reliability and reduce maintenance interruptions in the field. The design includes three rows of two-piece edge bent s-tines on overall 6" spacing. 23" of under frame shank clearance improves trash flow through the machine. A leveling device in front pf the rear roller helps level ridges left by the shanks. The 3600 Series also features the largest pulverizer wheels ever used by Brillion; all models in this series are equipped with 24" notched ductile iron wheels to provide even more clod crushing power.


Brillion's Puli-Mulcher line also includes three other well-known series besides the 3600 Series heavy-weights. The WL Series, available in sizes from 21'8" to 30', features 4" roller axles, a choice of 20" notched or crowfoot ductile iron wheels and two rows of either conventional 'c' tines or 's' tines. These models are flat-folding for a narrow transport width and manageable height.


The ML Series revolutionized the Pulvi-Mulcher industry when it was first introduced. Easier pulling 20" ductile iron rollers and a high clearance frame brought new life to the Pulvi-Mulcher. The long frame members allow more room for residue to flow through the machine. The ML Series is available in sizes from 12'6" to 18'9" and fits the needs of mid-sized operations by offering all of the benefits of a full-featured machine without the investment of the larger wing fold models.


The M Series, available in sizes from 7'4" to 10'4", rounds out the Brillion Pulvi-Mulcher line-up. These models utilize the rugged and reliable features of the original Pulvi-Mulcher. Sized and priced to fit operations with lower horsepower tractors and other niche markets, the M Series offers the solution to many seedbed preparation issues.

Cart
Call to order:
229-759-2484

3631 Series:

  • 3-section folding models in 25', 30' and 36' working widths
  • Designed for improved residue flow through the machine
  • Three rows of shanks on overall 6" spacing
  • 2-piece edge bent s-tine shanks for better leveling
  • 23" under frame clearance
  • 18" between shanks, minimum of 24" between rows
  • 2" reversible points
  • Maximum shank operating depth of 5"
  • Two-row coil tine harrow in front of rear roller
  • 8" roller axles
  • 61 mm heavy-duty bearings
  • 24" notched ductile iron wheels
  • Rear scrapers standard on notched rollers
  • From transport hitch floats 25 degrees up and 17 degrees down
  • Wings float 6 degrees down
  • Single point depth control
  • Wing hydraulic down pressure
  • Dual transport wheels
  • (4) 320/70 R 15 tires on 25' model
  • (4) 380/55 R X 16.5 tires on 30' model
  • (4) 480X45 R 17 tires on 36' model
  • Cat. III, IV or V hitch
  • Transport height - 9'6" for 25' & 30' model; 13'8" for 36' model
  • Transport width - 14'8" for 25' model; 17' for 30' model; 18'10" for 36' model
  • LED warning lights and SMV emblem
  • Safety chain kit
  • Powder coat paint

3620 Series:

  • 2-section folding models in 21' working widths
  • Designed for improved trash flow through the machine
  • Three rows of shanks of overall 6" spacing
  • Two-piece edge bent s-tine shanks for better leveling
  • 25" under frame shank clearance
  • 18" between shanks, minimum of 24" between rows
  • 2" reversible points
  • Maximum shank operating depth of 5"
  • Two-row coil tine harrow in front of rear roller
  • 8" roller axles
  • 61 mm heavy-duty bearings
  • Choice of 20" notched ductile iron wheels, 24" notched ductile iron wheels, 20" crowfoot ductile iron wheels or 20" optimizer ductile iron wheels
  • Rear scrapers standard on notched rollers
  • Hitch floats 10 degrees up, 35 degrees down
  • Wing float 5 degrees down
  • Hydraulic down pressure for even machine weight distribution across the width of machine
  • Independent hydraulic tooth depth control
  • Dual transport wheels
  • (4) 12.5L X 15 F 1 tires
  • Cat. II, III or IV hitch
  • Transport height - 13'4"
  • Transport width - 12'3"
  • LED warning lights & SMV emblem
  • Safety chain kit
  • Powder coat paint

WL Series:

  • Flat folding models in sizes from 21'8" to 30'
  • Choice of 20" notched ductile iron or 20" crowfoot ductile iron Pulverizer wheels on front axle
  • Choice of 20" notched ductile iron or 20" crowfoot ductile iron Pulverizer wheels on rear axle
  • 4" roller axles with sealed bearings
  • External bearing mount allows for easy service
  • Fully adjustable reversible scrapers standard for rear rollers equipped with notched wheels
  • Choice of conventional "c" teeth or 's-tine" teeth
  • Teeth spaced at 6"
  • Maximum depth operation of 6"
  • Flip-flop style hitch
  • Extra long hitch accommodates dual wheel tractors
  • Hitch point at center height of front roller axle
  • Coil spring counter balance on 21'8" and 25' models provides smooth, jolt-free operation
  • Integral hydraulic counter balance on 30' models
  • Mechanical transport lock
  • Frame members made of 4" X 6" structural steel tubing provide structural integrity and reliability
  • Heavy-duty transport rockshaft with dual wheels
  • 11L X 15-12 Ply Implement tires on 21'8" and 25' models
  • 12.5L X 16-14 Ply Implement tires on 30' models
  • Independent hydraulic tooth control standard equipment
  • Rear hitch available
  • Land leveler and V-leveler kits available
  • Front roller scrapers available for front rollers equipped with notched wheels
  • Safety warning lights
  • Powder coat paint

ML Series:

  • Rigid, non-folding models available in sizes from 12'6" to 18'9"
  • Choice of 20" notched ductile iron or 20" crowfoot ductile iron Pulverizer wheels on front axle
  • Choice of 20" notched ductile iron or 20" crowfoot ductile iron Pulverizer wheels on rear axle
  • 4" roller axles with sealed bearings
  • External bearing mount allows for easy service
  • Fully adjustable reversible scrapers standard for rear rollers equipped with notched wheels
  • Choice of conventional "c" teeth or "s-tine" teeth
  • Teeth spaced at 6"
  • Maximum depth of operation 6"
  • Flip-flop style hitch
  • Long hitch accommodates dual wheel tractors
  • Hitch point at center height of front roller axle
  • Spring loaded counter balance provides positive machine control
  • Mechanical transport lock
  • Frame members made of 4" x 6" structural steel tubing provide structural integrity and reliability
  • Heavy-duty transport rockshaft with dual wheels
  • 9.5L X 15-8 Ply Tires
  • Independent hydraulic tooth control standard equipment
  • Rear hitch available
  • Land leveler and V-leveler kits available
  • Front roller scrapers available for front rollers equipped with notched wheels
  • Safety warning lights
  • Powder coat paint

M Series:

  • Available in sizes from 7'4" to 10'4"
  • Choice of 16" notched gray iron or 16" crowfoot gray iron Pulverizer wheels on front axle
  • Choice of conventional "c" teeth or "s-tine" teeth
  • Teeth spaced at 6"
  • Maximum depth operation 4"
  • Pull-type with hydraulic lift
  • 7.60 X 15-6 Ply implement tires
  • Front scraper kit available for front axles equipped with notched gray iron wheels
  • Land leveler kit available
  • Safety warning lights on 10'4" models
  • Powder coat paint
