JAYLOR Twin auger series

JAYLOR Twin auger series Image
JAYLOR Twin auger series Image
JAYLOR Twin auger series

5600

  • Capacity no extension - 615 cubic feet, 17.4 cubic m
  • Capacity 8" extension - 675 cubic feet, 19.1 cubic m
  • Capacity 12" extension - 720 cubic feet, 20.4 cubic m
  • Capacity 16" extension - 765 cubic feet, 21.7 cubic m

5650

  • Capacity no extension - 650 cubic feet, 18.4 cubic m
  • Capacity 8" extension - 700 cubic feet, 19.8 cubic m
  • Capacity 12" extension - 740 cubic feet, 21.0 cubic m
  • Capacity 16" extension - 780 cubic feet, 22.1 cubic m

5750

  • Capacity no extension - N/A
  • Capacity 8" extension - N/A
  • Capacity 12" extension - 740 cubic feet, 21.0 cubic m
  • Capacity 16" extension - 780 cubic feet, 22.1 cubic m

5850

  • Capacity no extension - 800 cubic feet, 22.7 cubic m
  • Capacity 8" extension - 865 cubic feet, 24.5 cubic m
  • Capacity 12" extension - 910 cubic feet, 25.8 cubic m
  • Capacity 16" extension - 960 cubic feet, 27.2 cubic m
Cart
Call to order:
229-759-2484

5600

  • Weight - 12900 lbs. or 5900 kg
  • Height - 93 in. or 236 cm
  • Length - 303 in. or 770 cm
  • Drum width - 97 in. or 246 cm
  • PTO speed - 540 RPM
  • Minimum HP requirements - 105 HP
  • Auger speed - 41 RPM
  • Number of knives - 18
  • Auger flighting thickness - 5/8 in. or 16 mm
  • Max discharge height - 60 in. or 152 cm
  • Conveyor width - 36 in. or 91 cm
  • Door opening width - 42 in. or 107 cm
  • Floor thickness - 5/8 in. or 16 mm
  • Drum wall thickness - 1/4 in. or 6 mm
  • Standard tires - 12.5L-15FI LR "F" (4)
  • Wheel assembly - Dual oscillating

5650

  • Weight - 12700 lbs. or 5800 kg
  • Height - 102 in. or 259 cm
  • Length - 290 in. or 737 cm
  • Drum width - 9 in. or 231 cm
  • PTO speed - 540 RPM
  • Minimum HP requirements - 115 HP
  • Auger speed - 38 RPM
  • Number of knives - 18
  • Auger flighting thickness - 5/8 in. or 16 mm
  • Max discharge height - 60 in. or 152 cm
  • Conveyor width - 36 in. or 91 cm
  • Door opening width - 42 in. or 107 cm
  • Floor thickness - 5/8 in. or 16 mm
  • Drum wall thickness - 1/4 in. or 6 mm
  • Standard tires - 12.5L-15FI LR "F" (4)
  • Wheel assembly - Dual oscillating

5750

  • Weight - 13000 lbs. or 5900 kg
  • Height - 112 in. or 284 cm
  • Length - 290 in. or 737 cm
  • Drum width - 91 in. or 231 cm
  • PTO speed - 1000 RPM
  • Minimum HP requirements - 115 HP
  • Auger speed - 38 RPM
  • Number of knives - 18
  • Auger flighting thickness - 5/8 in. or 16 mm
  • Max discharge height - 60 in. or 152 cm
  • Conveyor width - 36 in. or 91 cm
  • Door opening width - 42 in. or 107 cm
  • Floor thickness - 5/8 in. or 16 mm
  • Drum wall thickness - 1/4 in. or 6 mm
  • Standard tires - 15.0/55-17 26 Ply (4)
  • Wheel assembly - Dual oscillating

5850

  • Weight - 13500 lbs. or 6100 kg
  • Height - 108 in. or 274 cm
  • Length -308 in. or 782 cm
  • Drum width - 97 in. or 246 cm
  • PTO speed - 1000 RPM
  • Minimum HP requirements - 125 HP
  • Auger speed - 38 RPM
  • Number of knives - 18
  • Auger flighting thickness - 5/8 in. or 16 mm
  • Max discharge height - 60 in. or 152 cm
  • Conveyor width - 36 in. or 91 cm
  • Door opening width - 42 in. or 107 cm
  • Floor thickness - 5/8 in. or 16 mm
  • Drum wall thickness - 1/4 in. or 6 mm
  • Standard tires - 15.0/55-17 26 Ply (4)
  • Wheel assembly - Dual oscillatong
